Product Name：RVW Chip/SMD Aluminum Electrolytic Capacitor
Series：RVS
Operating Temperature Range°C：-40°C~+85°C
Working Voltage Range：6.3V~100Vdc
Capacitance Range：1uF~1500uF
Load life：3000hours
RVW Chip Aluminum Electrolytic Capacitor, Surface Mount Aluminum Electrolytic Capacitor SMD, V-Chip
Reflow soldering available for reflow soldering
Bi-polarized
Available for high density surface soldering
Life time: 105C 3000Hours
Adapted to the ROHS / REACH directive
Related Voltage: 6.3V, 10V, 16V, 25V, 35V, 50V, 63V, 100V.
Related Capacitance: 1.0uF, 2.2uF, 3.3uF, 4.7uF, 6.8uF,8.2uF,10uF,22uF,33uF,47uF,100uF, 220uF RVW 3000hours 105C Chip Aluminum Electrolytic Capacitor, Surface Mount Aluminum Electrolytic Capacitor SMD, V-Chip
