Product Name：RVH Chip/SMD Aluminum Electrolytic Capacitor
Series：RVH
Operating Temperature Range°C：-40~+125°C
Working Voltage Range：6.3V~50V
Capacitance Range：10uF~470uF
Load life：2000Hours
RVH High Temperature Chip/SMD Aluminum Electrolytic Capacitor
• Reflow soldering available for reflow soldering
• Available for high density surface soldering
• Life time:125°C 2000Hours
• Adapted to the ROHS / REACH directive
Related Voltage: 6.3V, 10V, 16V, 25V, 35V, 50V.
Related Capacitance: 10uF,22uF,33uF,47uF,68uF,100uF, 220uF, 330uF, 470uF.
Chip/SMD Aluminum Electrolytic Capacitor Extremely Low Impedance.
