RVZ Chip/SMD Aluminum Electrolytic Capacitor
Product Name:RVZ Chip/SMD Aluminum Electrolytic Capacitor
Operating Temperature Range°C:-55~+105°C
Working Voltage Range:6.3V~50Vdc
Capacitance Range:1uF~1500uF
Load life:2000Hours
  RVZ Extremely Low Impedance Chip/SMD Aluminum Electrolytic Capacitor
 • Reflow soldering available for reflow soldering
 • Available for high density surface soldering
 • Extremely Low Impedance
 • Life time:105°C 2000~3000Hrs product

 • Adapted to the ROHS / REACH directive

Related Voltage: 6.3V, 10V, 16V, 25V, 35V, 50V.
Related Capacitance: 1uF,2.2uF,3.3uF,4.7uF,10uF,22uF,33uF,47uF,68uF,100uF,150uF,220uF,330uF,


Chip/SMD Aluminum Electrolytic Capacitor Extremely Low Impedance.
